型號 |
回轉 直徑 D |
公稱轉矩
Tn kN.m |
疲勞轉矩 Tf kN.m |
軸線折角 β |
伸縮量 Ls |
尺寸 |
轉動貫量kg.m2 |
質量 kg | |||||||||||
|
Lmin |
D1 (js11) |
D2 (H7) |
D3 |
Lm |
n-d |
k |
t |
b (h9) |
g |
Lmin |
增長 100mm |
Lmin |
增長 100mm | ||||||
|
SWC180DH1 |
180 |
12.5 |
6.3 |
≤25 |
75 |
650 |
155 |
105 |
114 |
110 |
8-17 |
17 |
5 |
- |
- |
0.165 |
0.0070 |
58 |
2.8 |
|
SWC180DH2 |
55 |
600 |
0.162 |
56 | |||||||||||||||
|
SWC180DH3 |
40 |
550 |
0.160 |
52 | |||||||||||||||
|
SWC225DH1 |
225 |
40 |
20 |
≤15 |
85 |
710 |
196 |
135 |
152 |
120 |
8-17 |
20 |
5 |
32 |
9.0 |
0.415 |
0.0234 |
95 |
4.9 |
|
SWC225DH2 |
70 |
640 |
0.397 |
92 | |||||||||||||||
|
SWC250DH1 |
250 |
63 |
31.5 |
≤15 |
100 |
795 |
218 |
150 |
168 |
140 |
8-19 |
25 |
6 |
40 |
12.5 |
0.900 |
0.0277 |
148 |
5.3 |
|
SWC250DH2 |
70 |
735 |
0.885 |
136 | |||||||||||||||
|
SWC285DH1 |
285 |
90 |
45 |
≤15 |
120 |
950 |
245 |
170 |
194 |
160 |
8-21 |
27 |
7 |
40 |
15.0 |
1.876 |
0.0510 |
229 |
6.3 |
|
SWC285DH2 |
80 |
880 |
1.801 |
221 | |||||||||||||||
|
SWC315DH1 |
315 |
125 |
63 |
≤15 |
130 |
1070 |
280 |
185 |
219 |
180 |
10-23 |
32 |
8 |
40 |
15.0 |
3.331 |
0.0795 |
346 |
8.0 |
|
SWC315DH2 |
90 |
980 |
3.163 |
334 | |||||||||||||||
|
SWC350DH1 |
350 |
180 |
90 |
≤15 |
140 |
1170 |
310 |
210 |
267 |
194 |
10-23 |
35 |
8 |
50 |
16.0 |
6.215 |
0..2219 |
508 |
15.0 |
|
SWC350DH2 |
90 |
1070 |
5.824 |
485 | |||||||||||||||
|
SWC390DH1 |
390 |
250 |
125 |
≤15 |
150 |
1300 |
345 |
235 |
267 |
215 |
10-25 |
40 |
8 |
70 |
18.0 |
11.125 |
0.2219 |
655 |
15.0 |
|
SWC390DH2 |
90 |
1200 |
10.763 |
600 | |||||||||||||||
